Product Specification
WSD-SPT-60W Product Specification.pdf
Product Features ：
● Philips Lumileds LED, high luminous efficiency and long working life.
● High efficiency LED Driver, the wide range input voltage AC100-480V；
● Cast aluminium cooling design, better cooling, light quality, LED Tj < 85℃.
● Excellent optical design, greatly improved the light utilization and evenness.
● Excellent efficacy ≥130lm/w.
Product Applications：
WSD LED Post Top Lighting series can be widely used in Urban roads, industrial areas, residential areas, sidewalks, squares, parks, schools, gardens etc.
Structure Features：
● Shell materials: Aluminum & PC
● Color: Dark Bronze / White
● Net weight：2.90Kg
Technical Parameters：
| Type |
WSD-SPT06W27-XXK-Z |
||
| Power | 60W | Lighting Angle | 159℃ |
| Input Voltage | AC120~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.98 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 7800 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Wet Location/IP66 |
| CRI | Ra>80 | Cable | Input Connect, No Cable |
