Product Specification
WSD-GWP-70W Product Specification.pdf
Features:
● Philips Lumileds LED, high luminous efficiency and long working life.
● High efficiency LED Driver, the wide range input voltage AC120-277V.
● Dia cast aluminium cooling design , high quality and better cooling for LED Tj < 85℃.
● Excellent Optics design, greatly improve the light utilization and evenness.
● Photocell Control Available (Option)
Product Applications:
WSD LED GLASS WALL PACK Lighting series can be widely used in indoor or outdoor lighting（Wet location）, like mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station and indoor stadiums etc.
Structure Features:
● Shell materials: Aluminum & Glass
● Color: Dark Bronze / White
● Net weight：10.40 lbs (4.70kg) Kg Unit：mm
● Packing Size：450mm*315mm*310mm
Technical Parameters:
| Type | WSD-GWP07W27-XXK-Z-P | ||
| Power | 70W | Lighting Angle | 87*118℃ |
| Input Voltage | AC120~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.95 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 9100 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Wet Location/IP65 |
| CRI | Ra>70 | Cable | Input Connect, No Cable |
