Product Specification
WSD-GSK-45W Product Specification.pdf
Product Features：
● Philip Lumileds LED, high luminous efficiency and long life.
● High efficiency LED Driver, the wide range input voltage AC120-277V；
● Die cast Aluminum design, better cooling, light quality, LED Tj < 85℃.
● Excellent optical design, greatly improved the light utilization and evenness.
Product Applications：
Can be widely used in Gas Station.
Structure Features：
● Shell materials: Aluminum & Glass
● Color: White
Technical Parameters：
| Type | WSD-GSK45W27-XXK-XX | ||
| Power | 45W | Lighting Angle | 115℃ |
| Input Voltage | AC120~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.95 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 5990 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Wet Location/IP65 |
| CRI | Ra>80 | Optional dimming function | 1-10Vdc |
