Product Specification
WSD-SE-40W Product Specification.pdf
Product Features：
● Optical design, greatly improved the light utilization and evenness.
● High efficiency LED Driver, voltage AC120-277 / 277-480V.
● Cast Aluminum design, better cooling, light quality, LED Tj < 85℃.
● ExcelleAnt efficacy ≥130lm/w.
● 12V auxiliary dimming/Dali dimming (Option).
Structure Applications：
The Stadium Eyes LED Lighting Series can be widely used for Indoor or Outdoor (Wet Location) Excellent for Large outdoor fields -stadiums, riding arenas, baseball and football fields,Other large outdoor areas: parks, docks, shipyard,airport and many other applications.
Structure Features：
● Shell materials: Aluminum & PC
● Color: Dark Bronze/White/Black(option)
● Net weight：22.5/23.5 KG (49.6/51.8 LBS)
● Product Size: 690mmX546.7mmX277.2mm
● Carton Size: 790mmX720mmX290mm
Technical Parameter：
| Type |
WSD-SE40W27-XXK-Z-NM-U-E |
||
| Power | 400W | Lighting Angle | NAME III, IV, V |
| Input Voltage | AC120~277V or AC277~480V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.98 | L70 Life | >75,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 54098 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 4000K/5000K | Protection Level | Wet Location |
| CRI | Ra>80 | Cable | 3 core, 14AWG(1.5M) |
