Product Specification
WSD-P22/P14-FT36W Product Specification.pdf
Product Features：
● Flicker-free driver,0-10V dimming can be well compatible with most dimmers;
● Use high quality SMD2835 LEDs
● Human-friendly Junction driver box for fire-proofing and easy installation.
● Aluminum Alloy Frame: strong and firm due to special fabrication processing; frame color can be silver or white
● Installation: Recessed ; Suspended ; Surface-mounted.
Product Application :
WSD LED Panel Light series can be widely used in bank, cafe, hospital, office, residence, shopping mail, livingroom, plane and train etc.
Structure Features：
● Shell materials: PC
● Color: White
● Net weight：4.2Kg
Technical Parameter：
| Type |
WSD-P22FT36W-XXK |
||
| Power | 36W | Lighting Angle | 120℃ |
| Input Voltage | AC100~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.95 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 5000 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Damp |
| CRI | Ra>80 | Cable | 3 core, 18AWG(0.3M) |
