Product Specification
WSD-SWP-20W Product Specification.pdf
Product Features ：
● Philips Lumileds LED, high luminous efficiency and long working life.
● High efficiency LED Driver, the wide range input voltage AC120-277V；
● Cast aluminium cooling design, better cooling, light quality, LED Tj < 85℃.
● Excellent optical design, greatly improved the light utilization and evenness.
● Photocell Control Available ( Option)
Product Applications：
WSD LED WALL PACK Lighting series can be widely used in indoor or outdoor lighting（Wet location）, like mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station and indoor stadiums etc
Structure Features：
● Shell materials: Aluminum & PC
● Color: Dark Bronze / White
● Net weight：2.90Kg
Technical Parameters：
| Type |
WSD-SWP02W27-XXK-Z-Y |
||
| Power | 20W | Lighting Angle | 92℃ |
| Input Voltage | AC120~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.98 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 2600 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Wet Location/IP66 |
| CRI | Ra>80 | Cable | Input Connect, No Cable |
