Product Specification:
WSD-GSL-120W Product Specification.pdf
Product Features :
● Philips Lumileds LED, high luminous efficiency and long working life.
● High efficiency LED Driver, the wide range input voltage AC100-277V / AC200-480V.
● Die Casting aluminium cooling design better cooling, better cooling, light quality, LED Tj < 85℃.
● Excellent lampshade design, greatly improved the light utilization and evenness.
Product Applications：
WSD LED Gas Station Light series can be widely used in indoor or outdoor lighting , like in Parking garage,Gallery,Garden, Gas Station etc.
Structure Features：
● Shell materials: Aluminum & Glass
● Color: White
● Net weight: 8.50 Kg
Technical Parameters：
| Type | WSD-GSL12W27-XXK | ||
| Power | 120W | Lighting Angle | 113℃ |
| Input Voltage | AC100~277V | LED Brightness Decay | <5%/6000 hrs |
| PF | >0.95 | L70 Life | >140,000 hrs |
| Driver Efficiency | >90% | Working Temperature | -30-+45℃ |
| Luminous Flux | 14000 Lm | Storage Temperature | -40-+80℃ |
| Color Temperature | 3000K/4000K/5000K/5700K | Protection Level | Wet Location/IP65 |
| CRI | Ra>80 | Cable | Input Connect, No Cable. |
