Product Specification
WSD-GSL-100W Product Specification.pdf
Product Features：
● Lumileds LED, high luminous efficiency and long life.
● High efficiency LED Driver, the wide range input voltage AC100-277V；
● Die cast Aluminum design, better cooling, light quality, LED Tj < 85℃.
● Excellent optical design, greatly improved the light utilization and evenness.
Product Applications：
WSD LED Gas Station Light series can be widely used in indoor or outdoor lighting , like in Parking garage,Gallery,Garden, Gas Station etc.
Structure Features：
● Shell materials: Aluminum & Glass
● Color: White
● Net weight: 8.50 Kg
Technical Parameters：
|
Model No |
WSD-GSL10W27-XXK |
||
|
Power |
100W |
Luminous Flux |
11500LM |
|
Color Temperature |
4000K/5000K/6000K +/-300K |
CRI |
Ra＞80 |
|
Luminous Efficiency |
105LM/W |
LED Chip Brand |
Philips Lumileds |
|
Frequency Range |
47/63 Hz |
Beam Angle |
113°
|
|
Power Factor |
>90% |
LED Driver |
Inventronics |
|
Working Temperature |
-30°-+55°
|
Storage Temperature |
-40°-+80°
|
|
Input Voltage |
AC100-277V |
Net Weight |
8.50Kg |
|
Protection degree |
IP65 |
Warranty |
Aluminum Heat sink and Glass
|
